Off-Grid Solar Kit with Battery

Upgrade your energy independence with our state-of-the-art Off-Grid Solar Kit, featuring cutting-edge solar technology for reliable and sustainable power. This comprehensive package combines the efficiency of LONGi Hi-MO LR5-54HTB Mono 440W Solar Panels with the robust performance of a 5000W MUSTPOWER Hybrid Off-Grid Inverter, complemented by high-capacity Ultra Lead Carbon Batteries.

What’s Included:
A. 6 x LONGi Hi-MO LR5-54HTB Mono 440W Solar Panels: Enjoy maximum power output with advanced half-cell technology and a sleek black frame design. These panels come with a 25-year linear power output warranty and are designed to withstand harsh conditions (Dimensions: 1722x1134x30mm).

B. 1 x 5000W MUSTPOWER Hybrid Off-Grid Inverter PV18-5048 VHM: This inverter seamlessly manages your energy, whether from solar panels or batteries, ensuring pure sine wave output for sensitive electronics. With a 2-year warranty, it offers efficiency of up to 93% and supports both personal computers and home appliances with swift transfer times.

C. 4 x 12V 130Ah Ultra Lead Carbon Batteries with Battery Equalizers: These batteries are engineered for long life and deep cycling, providing reliable storage for your solar energy. Backed by a 2-year warranty, they ensure consistent power availability.

D. 2 x 10m Twin 4mm PV Extension Cable with MC4 Connectors: Quality cables ensure a secure and efficient connection between your solar panels and the inverter.

E. 1 x 2-in-1 MC4 Connector: Streamlines the connection process for multiple panels.

F.  x PV Safety System with Fuse Box: Protects your system with essential safety components.

G. 6 x Solar Panel Mounting Kits Z Brackets: Easy-to-install brackets ensure your panels are securely mounted.

Optional Upgrade: Swap out the mounting kits for Mounting Rails for an additional $145. Contact us for more details.

Inverter Specifications:
- Battery System Voltage: 48VDC
- Rated Power: 5000W, with a surge power of 10000W
- Waveform: Pure sine wave for high-quality output
- AC Voltage Regulation: ±5% (220VAC ~ 240VAC)
- Maximum PV Input Power: 3840W with an MPPT efficiency of 98%
- Maximum Charge Current: Up to 140A ensuring fast and efficient charging
- Dimensions: 297.5x468x125mm, with a lightweight design at 13.3kg
- SAA NZ Certification: Compliant with New Zealand safety standards

This solar kit is perfect for off-grid living, offering robust, reliable power with minimal maintenance. The optional upgrade to mounting rails enhances the versatility and installation process of the system. Take control of your energy future with a system designed to provide sustainable power, no matter where you are.
